TRANSMISSION, 8-SPEED AUTOMATIC

• (STD)

SEATS, FRONT BUCKET

• (STD)

AUDIO SYSTEM, PREMIUM GMC INFOTAINMENT SYSTEM WITH NAVIGATION AND 8" DIAGONAL COLOR TOUCH-SCREEN

• includes multi-touch display
• AM/FM stereo
• Bluetooth® streaming audio for music and most phones; featuring Android Auto and Apple CarPlay capability for compatible phones
• advanced voice recognition
• in-vehicle apps
• personalized profiles for infotainment and vehicle settings. Includes (MCR) Data ports and memory card.) (STD)

GVWR, 6000 LBS. (2722 KG)

• (STD)

LPO, SOFT FOLDING TONNEAU COVER

• (dealer-installed)

DENALI PREFERRED EQUIPMENT GROUP

• includes standard equipment

LPO, ALL-WEATHER FLOOR MATS

• (dealer-installed)

ENGINE, 3.6L DI DOHC V6 VVT

• (308 hp [230.0 kW] @ 6800 rpm
• 275 lb-ft of torque [373 N-m] @ 4000 rpm) (STD)

LPO, CARGO TIE-DOWN RINGS (SET OF 4)

• (dealer-installed)

• TRANSMISSION 8-SPEED AUTOMATIC (STD)
• SEATS FRONT BUCKET (STD)
• AUDIO SYSTEM PREMIUM GMC INFOTAINMENT SYSTEM WITH NAVIGATION AND 8 DIAGONAL COLOR TOUCH-SCREEN includes multi-touch display AM/FM stereo Bluetooth® streaming audio for music and most phones; featuring Android Auto and Apple CarPlay capability for compatible phones advanced voice recognition in-vehicle apps personalized profiles for infotainment and vehicle settings. Includes (MCR) Data ports and memory card.) (STD)
• GVWR 6000 LBS. (2722 KG) (STD)
• LPO SOFT FOLDING TONNEAU COVER (dealer-installed)
• DENALI PREFERRED EQUIPMENT GROUP includes standard equipment
• TRAILER BRAKE CONTROLLER INTEGRATED
• REAR AXLE 3.42 RATIO
• LPO ALL-WEATHER FLOOR MATS (dealer-installed)
• JET BLACK PERFORATED LEATHER-APPOINTED SEAT TRIM
• ONYX BLACK
• ENGINE 3.6L DI DOHC V6 VVT (308 hp [230.0 kW] @ 6800 rpm 275 lb-ft of torque [373 N-m] @ 4000 rpm) (STD)
• LPO CARGO TIE-DOWN RINGS (SET OF 4) (dealer-installed)
• Lane Departure Warning
• Front Collision Warning
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Aluminum Wheels
• Tires - Front All-Season
• Tires - Rear All-Season
• Temporary Spare Tire
• Conventional Spare Tire
• Running Boards/Side Steps
• Fog Lamps
• Heated Mirrors
• Power Mirror(s)
• Sliding Rear Window
• Bed Liner
• AM/FM Stereo
• Navigation System
• MP3 Capability
• Bluetooth® Connection
• Auxiliary Audio Input
• Smart Device Integration
• HD Radio
• Satellite Radio
• Requires Subscription
• Premium Sound System
• WiFi Hotspot
• Bucket Seats
• Leather Seats
• Power Driver Seat
• Power Passenger Seat
• Driver Adjustable Lumbar
• Passenger Adjustable Lumbar
• Heated Front Seat(s)
• Heated Front Seat(s)
• Cooled Front Seat(s)
• Heated Front Seat(s)
• Cooled Front Seat(s)
• Pass-Through Rear Seat
• Rear Bench Seat
• MP3 Capability
• Auxiliary Audio Input
• Floor Mats
• Floor Mats
• Leather Steering Wheel
• Adjustable Steering Wheel
• Steering Wheel Audio Controls
• Heated Steering Wheel
• Power Door Locks
• Power Windows
• Cruise Control
• Keyless Entry
• Power Door Locks
• Remote Engine Start
• Immobilizer
• Security System
• Climate Control
• A/C
• Rear Defrost
• Auto-Dimming Rearview Mirror
• Driver Vanity Mirror
• Passenger Vanity Mirror
• Driver Illuminated Vanity Mirror
• Passenger Illuminated Visor Mirror
• Front Reading Lamps
• Front Reading Lamps
• Traction Control
• Stability Control
• Traction Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Telematics
• Requires Subscription
• Rear Parking Aid
• Back-Up Camera
• Lane Departure Warning
• Front Collision Warning
• Driver Restriction Features
• Tire Pressure Monitor

• Mileage
• Fuel Economy Est-Combined (MPG): 19
• EPA Fuel Economy Est - City (MPG): 17
• EPA Fuel Economy Est - Hwy (MPG): 24
• Electrical
• Cold Cranking Amps @ 0° F (Primary): - TBD -
• Maximum Alternator Capacity (amps): - TBD -
• Maximum Alternator Watts: - TBD -
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 3200
• Gross Axle Wt Rating - Rear (lbs): 3500
• Curb Weight - Front (lbs): 2229
• Curb Weight - Rear (lbs): 1745
• Gross Vehicle Weight Rating Cap (lbs): 6000
• Gross Combined Wt Rating (lbs): 12000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 700
• Maximum Trailering Capacity (lbs): 7600
• Suspension
• Suspension Type - Front: Independent Coil
• Suspension Type - Rear: 2-Stage Multi-Leaf
• Spring Capacity - Front (lbs): 3200
• Spring Capacity - Rear (lbs): 3500
• Axle Type - Front: Independent
• Axle Type - Rear: Semi-Floating
• Axle Capacity - Front (lbs): 3200
• Axle Capacity - Rear (lbs): 3500
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Rear: 3.42
• Stabilizer Bar Diameter - Front (in): - TBD -
• Stabilizer Bar Diameter - Rear (in): - TBD -
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.2 x - TBD -
• Rear Brake Rotor Diam x Thickness (in): 12.75 x - TBD -
• Tires
• Front Tire Order Code: QQD
• Rear Tire Order Code: QQD
• Spare Tire Order Code: ZJJ
• Front Tire Size: 255/55R20
• Rear Tire Size: 255/55R20
• Spare Tire Size: 265/70R16
• Front Tire Capacity (lbs): 3200
• Rear Tire Capacity (lbs): 3500
• Spare Tire Capacity (lbs): - TBD -
• Revolutions/Mile @ 45 mph - Front: - TBD -
• Revolutions/Mile @ 45 mph - Rear: - TBD -
• Revolutions/Mile @ 45 mph - Spare: - TBD -
• Wheels
• Front Wheel Size (in): 20 x 8.5
• Rear Wheel Size (in): 20 x 8.5
• Spare Wheel Size (in): 16 x 7
• Front Wheel Material: Aluminum
• Rear Wheel Material: Aluminum
• Spare Wheel Material: Steel
• Steering
• Steering Type: Electric Rack & Pinion
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: - TBD -
• Turning Diameter - Curb to Curb (ft): 41.3
• Turning Diameter - Wall to Wall (ft): - TBD -
• Frame
• Frame Type: Fully-boxed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 21
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 128.3
• Length, Overall (in): 212.4
• Width, Max w/o mirrors (in): 74.3
• Height, Overall (in): 70.6
• Overhang, Front (in): 36.9
• Overhang, Rear w/o bumper (in): 47.2
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): 23.94
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 8.2
• Ground Clearance, Rear (in): 8.2
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 61.7
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 57.8
• Cargo Box Width @ Wheelhousings (in): 44.4
• Cargo Box (Area) Height (in): - TBD -
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): - TBD -
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 5
• Front Head Room (in): 41.4
• Front Leg Room (in): 45
• Front Shoulder Room (in): 57.5
• Front Hip Room (in): 55
• Second Head Room (in): 38.3
• Second Leg Room (in): 35.8
• Second Shoulder Room (in): 56.2
• Second Hip Room (in): 53.3
• Summary
• Vehicle Name: GMC Canyon
• Body Style: Crew Cab Pickup
• Body Code: E63
• Emissions
• Tons/yr of CO2 Emissions @ 15K mi/year: 9.3
